The pneumatic conveying system, a highly efficient material transportation method, is widely used in various fields. The following is a detailed introduction to its principle, characteristics, advantages, and applications:
Definition
The pneumatic conveying system is a device that uses air or other gases as the conveying medium. It propels solid materials through the energy generated by the gas flow in the pipeline, enabling the transportation of materials in horizontal, inclined, or vertical directions.
Principle
- Dilute - phase Conveying Principle**: Relying on high - speed gas flow, the materials are suspended in the pipeline. The kinetic energy of the gas flow is converted into the kinetic and potential energy of the materials, driving the materials to flow in the pipeline for transportation. Generally, the gas velocity is high, the material concentration is low, and the materials are evenly distributed in the pipeline.
- Dense - phase Conveying Principle: By using a lower gas flow velocity and higher gas pressure, the materials form mass flow or plug flow in the pipeline. The gas pressure pushes the "mass" or "plug" of materials to move forward in the pipeline, completing the conveying process. At this time, the material concentration is high, and the gas velocity is relatively low.
Characteristics
- Flexible Pipeline Layout: The conveying pipeline can be laid flexibly according to the site and process requirements. It can adapt to complex production environments, bypass obstacles, and achieve transportation in different directions.
- Isolation of Materials from the Environment: The materials are conveyed in a closed pipeline, which can effectively prevent dust from flying, protect the materials from getting damp and contaminated. At the same time, it can avoid dust pollution to the environment, ensuring a clean production environment and the quality of the materials.
- Capability to Convey Various Materials: It can convey various forms of materials such as powder, granules, and small pieces, such as cement, pulverized coal, grains, sand, plastic pellets, etc., with a wide range of applications.
- High Degree of Automation: It can be integrated with an automated control system. By controlling parameters such as gas pressure, flow rate, and velocity, quantitative and timed conveying of materials can be achieved, reducing manual intervention and improving production management levels.
Advantages
- High Efficiency and Energy - Saving: In the transportation of materials over long distances and in large volumes, it has a high conveying speed and large conveying capacity. Compared with some mechanical conveying methods, its energy consumption is relatively low, which can reduce production costs.
- Low Maintenance Cost: The system has a relatively simple structure and few moving parts. Except for power equipment, the pipeline and other conveying components have almost no wear and tear. The maintenance workload is small, and the service life of the equipment is long.
- Easy for Multi - point Conveying: Multiple feeding and discharging points can be set on the same conveying pipeline. It is convenient to collect materials from multiple locations and transport them to the same place, or transport materials from one place to multiple destinations, meeting the requirements of different production processes.
- Good Environmental Performance: Since the materials are conveyed in a closed pipeline, dust emissions and material leakage are reduced, resulting in less environmental pollution. It meets environmental protection requirements and is suitable for occasions with high environmental quality requirements.
Applications
- Industrial Field: In industries such as chemical engineering, building materials, and power, it is used to convey various raw materials, intermediate products, and finished products, such as chemical raw materials, cement raw meal and clinker, and pulverized coal in power plants.
- Grain Processing Industry: It is used for the transportation, lifting, and distribution of grains. For example, it can transport wheat, corn, etc., from the warehouse to the processing workshop or transfer materials between different processes in the workshop.
- Food Industry: It is suitable for the transportation of food raw materials and semi - finished products such as milk powder, sugar powder, and grain granules, ensuring the hygiene and quality of food during the transportation process.
- Pharmaceutical Industry: It is used for the transportation of pharmaceutical raw materials, granules, powders, etc., meeting the high - precision and high - cleanliness requirements for material transportation in the pharmaceutical manufacturing process.
- Port Logistics Field: It can be used for the loading, unloading, and transportation of bulk cargo at ports, such as transporting coal, ore, etc., from cargo ships to stockyards or from stockyards to transfer equipment.
 |  |
